Omron NYB1E-C1006 [222/276] Appendices
![Omron NYB1E-C1006 [222/276] Appendices](/views2/1872506/page222/bgde.png)
Item Default / Remark
Processor
(Integrated
Components)
Memory Configuration Force Single Rank Disabled
Memory Remap Enabled
Time Measure Disabled
DLL Weak Lock Support Enabled
Pwr Down Idle Timer 0
Mrc Fast Boot Enabled
Lpddr Mem WL Set Set B
EV Loader Disabled
EV Loader Delay Enabled
Graphics Configuration Primary Display Auto
External Gfx Card Primary Display
Configuration
Primary PEG = Auto
Primary PCIE = Auto
Internal Graphics Device Auto
GTT Size 8MB
Aperture Size 256MB
IGD Pre-Allocated Graphics Memo-
ry
32M
IGD Total Graphics Memory 256M
PM support Disabled
PAVP Enable Enabled
Cdynmax Clamping Enable Enabled
Cd Clock Frequency 675 Mhz
GOP Config Driver Enabled
IUER Button Enable Disabled
DMI/OPI Configuration DMI Max Link Speed Auto
DMI Gen3 Eq Phase 2 Auto
DMI Gen3 Eq Phase 3 Method Auto
DMI Vc1 Control Disabled
DMI Vcm Control Enabled
Program Static Phase1 Eq Enabled
Gen3 Root Port Preset value for
each Lane
All values = 4
Gen3 Endpoint Preset value for
each Lane
All values = 7
Gen3 Endpoint Hint value for each
Lane
All values = 2
Gen3 RxCTLE Control All values = 3
DMI Link ASPM Processor Side Disabled
DMI Extended Sync Control Disabled
DMI De-emphasis Control -3.5 dB
DMI IOT Disabled
Appendices
A-22
NY-series Industrial Box PC Hardware User's Manual (W553)
