6 Remove the PCIe Card from the PCIe Drawer.
2
1
The PCIe Card is now removed.
7 Place the replacement PCIe Card in the PCIe Drawer.
1
2
Ensure the PCIe Card is inserted into the correct opening.
7 Maintenance
7-18
NY-series Industrial Box PC Hardware User's Manual (W553)
