BIOS - Boot
This section provides BIOS Boot information for the 6
th
and 7
th
generation CPUs.
Changeable BIOS Boot parameters and their factory default values:
Item Default / Remark
Quiet Boot Disabled
Setup Prompt Timeout 1
Bootup NumLock State On
Power Loss Control
*1
Remain Off
AT Shutdown Mode
*3
Hot S5
Enter Setup If No Boot Device No
Enable Popup Boot Menu Yes
Boot Priority Selection Type Based
Boot Option Sorting Method
*3
UEFI First
Type Based Boot Priority
*3
1st Boot Device
CPU specific
*2
2nd Boot Device Disabled
3rd Boot Device Disabled
4th Boot Device Disabled
5th Boot Device Disabled
6th Boot Device Disabled
7th Boot Device Disabled
8th Boot Device Disabled
Battery Support
*3
Auto (Battery Manager)
System Off Mode
*3
G3/Mech Off
UEFI Fast Boot Disabled
UEFI Screenshot Capability Disabled
*1. Power Loss Control settings are :
Remain OFF: The Industrial Box PC will stay OFF when power is supplied to the power connector
Turn ON: The Industrial Box PC will automatically start up when power is supplied to the power connector.
Last State: The Industrial Box PC will start up or remain OFF when power is supplied based on the Industri-
al Box PC state at the moment power was removed from the power connector.
*2.
For 7
th
generation CPUs: SA
T
A 1 Drive.
For 6
th
generation CPUs: SA
TA 2 Drive.
*3.
Not applicable for CPU type Intel
®
Core
™
i7-7820EQ
Boot settings specific for CPU type Intel
®
Core
™
i7-7820EQ:
Item Default / Remark
Boot Option #1
Windows Boot Manager (P1: CFast £)
Boot Option #2
UEFI OS (P1: CFast £)
New Boot Option Policy Default
Appendices
A-29
NY-series Industrial Box PC Hardware User's Manual (W553)
