1-6-2
Industrial Box PC
The Industrial Box PC is designed to meet the specific needs of the industrial environment. Design
simplification and future-proof architecture minimize the risk of failure. In addition, new PC features
can be seamlessly incorporated, without the need for wholesale redesign. Examples are IPCs with a
Machine Controller or IPCs designed specifically for an Autonomous Mobile Robot (AMR).
1-6-3
Industrial Panel PC
The Industrial Panel PC intelligently combines the functionality of the Industrial Box PC and Industrial
Monitor
. No cables are used between the two components, which ensures optimal signal distribution
and reliable operation in industrial environments.
1 Overview
1-9
