Omron NYB1E-C1006 [207/276] Appendices
![Omron NYB1E-C1006 [207/276] Appendices](/views2/1872506/page207/bgcf.png)
Item Default / Remark
PCI & PCI Express PCI Express Gen 2 Set-
tings
Completion Timeout Default
ARI Forwarding Disabled
AtomicOp Requester En-
able
Disabled
AtomicOp Egress Block-
ing
Disabled
IDO Request Enable Disabled
IDO Completion Enable Disabled
LTR Mechanism Enable Disabled
End-End TLP Prefix
Blocking
Disabled
Target Link Speed Auto
Clock Power Manage-
ment
Disabled
Compliance SOS Disabled
Hardware Autonomous
Width
Enabled
Hardware Autonomous
Speed
Enabled
PCI Express Gen3 Set-
tings (for Port 0 and 1)
*1
Run-time C7 Allowed Disabled
Detect Non-compliant De-
vice
Disabled
Program PCIe ASPM af-
ter OpROM
Disabled
PEG Sampler Calibrate Disabled
Swing Control Full
Peg Gen3 Equalization Enabled
- Gen3 EQ Phase 2 Enabled
- PEG Gen3 Root Port
Preset V
alue for each
Lane. Lane 0...15
8
- PEG Gen3 Endpoint
Preset Value for each
Lane. Lane 0...15
7
- PEG Gen3 Endpoint
Hint Value for each Lane.
Lane 0...15
2
- Gen3 Eq Preset Search Enabled
– Always Re-search Gen3
Eq Preset
Disabled
– Preset Search Dwell
T
ime
1000
– Error T
arget 1
PEG RxCEM Loopback
Mode
Disabled
PCIe Gen3 RxCTLEp
Setting. PCIe Gen3
RxCTLEp 0...7
8
Appendices
A-7
NY-series Industrial Box PC Hardware User's Manual (W553)
A-1 BIOS
A
A-1-2 BIOS for 4
th
generation CPUs
