Cautions
CAUTION
Installation
When installing or removing a PCIe card, avoid touching the sharp edges of the sheet
metal frame tab. Injury may result.
Wiring
The product has an internal non-isolated DC power supply. Circuit ground (0 VDC) and
frame ground are connected together. When connecting a non-isolated device or a non-
isolated interface to the product, take appropriate actions to avoid communication fail-
ures or damage to the mentioned ports.
Industrial PC Platform Product
Non-isolated
Device
Non-isolated
Interface
24 VDC
0 VDC
Never ground the 24 VDC side of the power supply. This may cause a short circuit.
Safety Precautions
17
NY-series Industrial Box PC Hardware User's Manual (W553)
