BIOS - Chipset
This section provides Chipset information for a Box PC with an Atom CPU.
Changeable BIOS Chipset parameters and their factory default values:
Item Default / Remark
Processor
(Integrated
Components)
Max TOLUD 2 GB
Above 4GB MMIO BIOS assignment Disabled
Extention Graphic
Configuration
GOP Driver Enabled
Intel Graphics Pei Display Peim Disabled
Integrated Graphics Device Enabled
Primary Display IGD
RC6(Render Standby) Disabled
GTT Size 8MB
Aperture Size 256MB
IGD Pre-Allocated Graphics Memory 64M
IGD Total Graphics Memory 256M
GT PM Support Enabled
South Cluster
Configuration
SATA Drives Chipset SATA Enabled
SATA Port 0 Enabled
SATA Port 1 Enabled
USB Configuration USB Port Disable Override Disabled
Miscellaneous Config-
uration
Wake On Lan Disabled
Appendices
A-63
NY-series Industrial Box PC Hardware User's Manual (W553)
