Item Default / Remark
SMART Settings
Smart Self Test
*6
Disabled
UEFI Network Stack UEFI Network Stack Disabled
NVMe Configuration No NVME device found
Intel® Ethernet
Connection I218-LM -
Unique MAC Address
NIC Configuration Link Speed Auto Negotiated
Wake On LAN Enabled
Blink LEDs 0
*1.
Only for Box PCs with a CPU type Intel
®
Core
™
i7-4700EQ
.
*2.
Only for Box PCs with a CPU type Intel
®
Core
™
i5-4300U
.
*3.
Only for Box PCs with a CPU type Intel
®
Celeron
®
2980U.
*4. The active PCI Express Port number is related to the CPU type
• Box PCs with an Intel
®
Core
™
i7-4700EQ
CPU type use Port 0..5
• Box PCs with an Intel
®
Core
™
i5-4300U CPU type use Port 2 and 3
• Box PCs with an Intel
®
Celeron
®
2980U CPU type use Port 2 and 3
*5.
• Box PCs with an Intel
®
Celeron
®
2980U
CPU type only Port 0 and 1 are available
• Box PCs with an Intel
®
Core
™
i5-4300U CPU type Port 1 is Disabled
• Box PCs with an Intel
®
Core
™
i7-4700EQ CPU type Port 1 is Disabled. For Port 2: SATA Port = Enabled.
*6. Smart Self Test monitors the status of the HDD/SSD.
Enable only when Smart Monitoring software is used.
BIOS - Chipset
This section provides Chipset information for 4
th
generation CPUs.
Changeable BIOS Chipset parameters and their factory default values:
Item Default / Remark
Platform Controller Hub
(PCH)
PCI Express Clock Gating Disabled
DMI Link ASPM PCH Side Disabled
DMI Link Extended Synch Control Disabled
Isolate SMBus Segments During POST
PCIe-USB Glitch W/A Disabled
USB Precondition Disabled
BTCG Enabled
HDA Controller Auto
HDA PME Disabled
PCH LAN Controller Enabled
Wake on LAN Enabled
Serial IRQ Mode Continuous
SB CRID Disabled
Port 80h Redirection LPC Bus
Subtractive Decode Disabled
Processor (Integrated
Components
VT-d
*1
*2
Enabled
Audio Device (B0:D3:F0) Enabled
NB CRID Disabled
BDAT ACPI Table Support Disabled
*1.
Only for Box PCs with a CPU type Intel
®
Core
™
i5-4300U
.
*2.
Only for Box PCs with a CPU type Intel
®
Core
™
i7-4700EQ
.
Appendices
A-10
NY-series Industrial Box PC Hardware User's Manual (W553)
