Skil 4370 LD [10/112] Application advice

! always select “all/curve” when sawing splinter-

sensitive material

• Adjusting sawing speed to material used 0

! if the tool does not run with wheel D in position 1,

select a higher sawing speed and lower the

sawing speed while the tool runs

• Dust suction !a

! do not use vacuum cleaner when cutting metal

• Dust blowing !b

• Spot light @ (4370)

• Operating the tool

- before switching on the tool, ensure that front end of

footplate rests at on the workpiece

- hold tool rmly with both hands, so you will have full

control of the tool at all times

! while working, always hold the tool at the

grey-coloured grip area(s) #

- ensure that complete surface of footplate rests rmly

on the workpiece

! ensure that the blade has come to a complete

standstill, before you lift the tool from the

workpiece

- keep ventilation slots G 2 uncovered

APPLICATION ADVICE

• Use the appropriate saw blades $

! use T-shank blades only %

• When cutting metals, lubricate saw blade regularly with oil

• For an accurate straight cut, guide tool with footplate

along the edge of a straight piece of wood ^

• Pre-drill a hole before making cut-outs &

• Splinter-free cutting

- cover cutting-line with several layers of wide tape

before cutting

- always face the good side of the workpiece down

• For more tips see www.skil.com

MAINTENANCE / SERVICE

• This tool is not intended for professional use

• Always keep tool and cord clean (especially ventilation

slots G 2)

! disconnect the plug before cleaning

• If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools

- send the tool undismantled together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skil.com)

ENVIRONMENT

• Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

- in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

- symbol * will remind you of this when the need for

disposing occurs

DECLARATION OF CONFORMITY

• We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC, 2006/42/EC,

2011/65/EU, 2009/125/EC (EU regulation 1194/2012)

• Technical file at: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆÎ¹Æ¼½ÊÇÇ¾¼½Æ

È½Ê¹ÌÁÇÆËŵÆ¿ÁÆ½½ÊÁÆ¿

ÍÊÇÈ½Ɠˁ˅ʿ˂Ê½¼¹Ɠ

Ä¹¾ÁÂÃ¿Ê¹¹¾

ÈÈÊÇÎ¹Ä¹Æ¹¿½Ê

09.12.2013

NOISE/VIBRATION

• Measured in accordance with EN 60745 the sound

pressure level of this tool is 90 dB(A) and the sound

power level 101 dB(A) (standard deviation: 3 dB), and the

vibration ✱ (hand-arm method; uncertainty K = 1.5 m/s²)

✱ when cutting wood 5.6 (4270) / 8.8 (4370) m/s²

✱ when cutting metal 6.7 (4270) / 13.3 (4370) m/s²

• The vibration emission level has been measured in

accordance with a standardised test given in EN 60745; it

may be used to compare one tool with another and as a

preliminary assessment of exposure to vibration when

using the tool for the applications mentioned

- using the tool for dierent applications, or with dierent

or poorly maintained accessories, may signicantly

increase the exposure level

- the times when the tool is switched o or when it is

running but not actually doing the job, may signicantly

reduce the exposure level

! protect yourself against the effects of vibration by

maintaining the tool and its accessories, keeping

your hands warm, and organizing your work patterns



Scie sauteuse 4270/4370

INTRODUCTION

• Cet outil est conçu pour eectuer des découpes et

coupes dans le bois, les matières plastiques, le métal, les

plaques en céramique et le caoutchouc, et est approprié

pour des coupes droites et curvilignes à 0° ou 45°

• L’éclairage de cet outil électroportatif est destiné à

éclairer l’espace de travail de l’outil; il n’est pas conçu

pour servir de source d’éclairage ambiant dans une pièce

(4370)

• Cet outil n’est conçu pour un usage professionnel

• Lisez et conservez ce manuel d’instruction 3
