Installation Instructions iCSPSA2
9
TOOLS REQUIRED FOR INSTALLATION
PARTS
1/8" (3.2mm)
#2
7mm
A (1)
G (3)
#10 x2-1/2"
(4.8 x 63.5mm)
B (1) C (1)
D (2)
E (1)
F (2)
H (12)
M4 x 12
J (4)
M4 x 20
K (4)
M4 x 30
M (4)
M4
N (4)
3/8"
(9.5mm)
P (4)
3/4"
(19.1mm)
Q (4)
M6 x 12
R (2)
#8 x 3/8"
(4.0 x 9.5mm)
S (1)
3/16"
(4.8mm)
T (1)
3/32"
(2.4mm)
L (2)
M4
[single arm mount]
[wall plate] [wall plate cover]
[wall plate cap]
[cover]
[adapter bracket]
