5. The Program section: Overview Nord Stage EX v6.x

Page 18

THE STORE BUTTON

The red STORE button is used when storing Programs (see “Storing Programs” on page 20).

PROGRAM BUTTONS

Below the DISPLAY are the six PROGRAM buttons (1- 6). They are used to load Programs, to access

menus and to load either of the two Organ Inits.

THE LIVE 1/2 BUTTONS

Pressing either of the LIVE 1/2 buttons will activate a Live buffer - see “About the Live 1&2 Buffers”

on page 19 for a description of this special memory feature. They are also used to load the Piano and

Synth Inits.

KB ZONES 2/3 BUTTONS

These buttons are used to activate keyboard zones. Each Program can have up

to three keyboard zones (Lower/Upper/High), and each instrument section can

be set to play across all, two or one of these zones - see “Keyboard Zones and

Dual Panel setups” on page 56.

MORPH ASSIGN BUTTONS

This section allows you to assign panel parameter(s) to be controlled using the Mod wheel, a control

pedal or keyboard aftertouch. Multiple parameters can be Morph-assigned so that when you for ex-

ample move the Mod wheel it will change the drawbars settings for the organ and the volume of the

piano section simultaneously. See “The Morph Assign feature” on page 60.

PANEL A/B BUTTONS

For each Program you have two independent Panels; A and B, where each Panel contains independent

instances and settings of the three instrument sections and effects. If you activate both Panels you can

use two instruments of the same type at the same time, e.g. two Piano instruments or a Split Organ

setup (see “About Split Organ Setups” on page 29. This is done by simultaneously pressing both

ANEL A and B buttons. When both panels are active you have access to six instrument sections and

eight effects sections (Effect 1 & 2, Delay and AmpSim/EQ x2).

One of the P

ANEL A & B buttons will then blink to indicate edit focus, i.e. which of the two Panel’s

settings that are currently shown and can be tweaked. To switch edit focus to the other Panel, press

the corresponding P

ANEL button.
