Nord Stage EX v6.x 13. Nord Sound Manager: Tabs
Page 85
PARTITION MEMORY INDICATOR
This indicates the usage of the selected partition's memory. The red area shows the used memory and
the green area indicates space that is available for additional sounds.
C
ANCEL BUTTON
Use this function if you need to cancel a process that is in progress. Certain functions like e.g. a re-
store process cannot be cancelled.
P
ROGRESS BARS
The two progress bars indicate the progress of an ongoing process. The upper bar shows the progres-
sion of the individual processes, and the lower indicates the status of the entire task.
M
ESSAGE AREA - TEXT AREA
The left part of the text area will present any confirmations or error messages from the Nord Sound
Manager.
The right part will indicate of a Nord Stage EX is connected to the computer and in communication
with the Nord Sound Manager. The OS version of the Stage will also be presented here.
UPDATES AND PIANO SAMPLES
Please visit our website at http://www.nordkeyboards.com to download any updates of the Nord
Sound Manager and sounds that have been released for the Nord Stage EX. These items will be avail-
able as free downloads in the Nord Stage EX download area.
