Nord Stage EX v6.x 11. System functions: MIDI menu
Page 69
The following items can be found on the MIDI menu:
Function Description Range/Values
MIDI Control
Local
Here you set whether the Nord Stage EX keyboard
and front panel controls should control internal Pro-
grams or only send MIDI. Local On is the normal
“play mode”. In Local Off mode, the front panel and
keyboard actions are transmitted via MIDI only and
do not control the internal sound(s) directly.
On (Default), Off
MIDI Panel A/B
Channel
This sets the MIDI channel for Panel A/B 1-16, Off (Default A ch 1)
(Default B ch 2)
MIDI Organ A/B
Channel
This sets the MIDI channel for the Organ section A/B.
If a channel is set here, you can assign the corre-
sponding instrument to no KB Zone at all, i.e., make it
active but available only through MIDI.
1-16, Off (Default off)
MIDI Piano A/B
Channel
This sets the MIDI channel for the Piano section A/B.
If a channel is set here, you can assign the corre-
sponding instrument to no KB Zone at all, i.e., make it
active but available only through MIDI.
1-16, Off (Default off)
MIDI Synth A/B
Channel
This sets the MIDI channel for the Synth section A/B.
If a channel is set here, you can assign the corre-
sponding instrument to no KB Zone at all, i.e., make it
active but available only through MIDI.
1-16, Off (Default off)
MIDI Dual KB
Channel
This sets the MIDI channel for an external keyboard
when using Dual KB mode - see page 59.
1-16, Off (Default 16)
MIDI Prog Change
Mode
This allows you to set whether you want Nord Stage
EX to transmit and/or receive MIDI Program Change
Messages.
Off, Send, Receive, Send
& Receive (Default)
MIDI Ctrl Change
Mode
This allows you to set whether you want Nord Stage
EX to transmit and/or receive MIDI Controller Mes-
sages.
Off, Send, Receive, Send
& Receive (Default)
Send MIDI Ctrl You can perform a dump of all MIDI Controllers for
the selected Panel. Hit Store to perform the dump.
See “Sending MIDI Controller dumps” on page 89.
Panel A, Panel B
Dump Program
Source
Here you can perform a MIDI SysEx dump of the cur-
rently selected Program or of all 126 Programs of the
internal memory (plus the Live buffers 1 & 2). See
“Sending Program dumps” on page 88.
One (Default), All
Dump Synth Sound Here you can perform a separate MIDI SysEx dump
of just the Synth memory settings. See “Sending
Synth Sound bank dumps” on page 89.
Slot A/B, Synth, Pad, Bass,
All (Default)
Instrument SysEx ID Most instruments have a unique Instrument ID #. If
more than one of the same instruments are con-
nected in a MIDI network, this ensures that no instru-
ment will receive SysEx dumps not intended for it.
1-16, All (Default)
