CLAVIA DMI AB CLAVIA NORD Stage 2 EX Compact [95/101] Mplementatio

Nord Stage EX v6.x 15. MIDI implementation: MIDI Implementation Chart

Page 93

MIDI IMPLEMENTATION CHART

Model: Clavia Nord Stage EX Eighty Eight/Seventy Six/Compact OS v4.x Date: 2008-12-09

Function Transmitted Recognized Remarks

MIDI Channels 1 – 16 1 – 16 Individual channels for Panel A and B.

Velocity

Note On/Off

Yes Yes Incoming Velocity data ignored for

Organ.

Release velocity sent but not received.

Aftertouch Yes Yes Channel aftertouch only.

Pitch Bend Yes Yes

Control Change Yes Yes See “MIDI Controller list” on page 90.

Program Change Yes Yes 0-125, 126=Live1,127= Live 2

System Exclusive Yes Yes See the MIDI Implementation section.
