Nord Stage EX v6.x 10. The Extern section: The Parameter section
Page 65
MIDI CC
This allows you send MIDI Control Change messages to control a parameter of your choice on the
external instrument. You first have to decide which Controller number the P
ARAMETER rotary en-
coder should send value changes for. This is done on the Extern Menu:
1. Press S
HIFT and the EXTERN button to access the Extern menu.
2. Use the P
AGE buttons to select the “Extern MIDI CC Number” menu page.
3. Use the V
ALUE DIAL to select a MIDI CC Number (0-119). You may want to check the manual
for the external instrument to see which parameters are assigned to which CC numbers.
4. Press the E
XIT (SHIFT) button briefly to exit.
If you now activate the MIDI CC button in the Parameter Select section, you can control the selected
external parameter using the P
ARAMETER rotary encoder in the Extern section. You can turn this off
on the Extern menu - see “Extern menu” on page 70. The external instrument may have to be set to
receive MIDI CC messages for this to function.
ABOUT SEND ON LOAD
You can set whether Program Change, Volume and MIDI CC messages are sent out when you load
a Program in Nord Stage EX. If you do not want this to occur, make sure “Send On Load” is set to
“Off” on the Extern menu.
