CLAVIA DMI AB CLAVIA NORD Stage 2 EX Compact [91/101] Page 89

Nord Stage EX v6.x 14. MIDI functions: Program, Controller and Synth Sound

dumps

Page 89

SENDING MIDI CONTROLLER DUMPS

1. Set up as in steps 1 and 2 in the previous description.

2. P

RESS SHIFT + MIDI and select the ‘Send MIDI Ctrl” menu item using the PAGE -/+ buttons.

Select to send all Controllers from Panel A or Panel B by using the V

ALUE DIAL or by pressing

the corresponding P

ANEL button.

3. Press the S

TORE button to send the dump to the MIDI OUT of Nord Stage EX. The STORE indi-

cator will stop flashing once the dump has been sent.

SENDING SYNTH SOUND BANK DUMPS

You can perform a separate MIDI SysEx dump of the Synth memory banks. You can select to send

a single sound from the currently active Panel, one of the category banks (Synth/Pad/Bass) or all

banks at once:

1. Set up as in steps 1 and 2 in the preceding description.

2. P

RESS SHIFT + MIDI and select the ‘Dump Synth Sound” menu item using the PAGE -/+ but-

tons. Select to send the synth patch from the active Panel, one synth category or all synth sounds

by using the V

ALUE DIAL.

3. Press the S

TORE button to send the dump to the MIDI OUT of Nord Stage EX. The Store indica-

tor will stop flashing once the dump has been sent.

RECEIVE MIDI SYSEX DUMPS

To receive a MIDI SysEx Dump, do like this:

1. Connect a cable from the MIDI Out on the transmitting device to MIDI I

N on the Nord Stage

EX.

2. Initiate the transmission on the transmitting device.

If the dump contained all Programs (All), it will replace all Programs currently stored in the Nord

Stage EX. If the dump contained only a single Program (One), it will be temporarily placed in the

currently selected Program memory location. You will then have to store the Program manually to a

memory location using the Store function (see “Storing Programs” on page 20).

PANIC

If notes should hang using the Nord Stage EX in a MIDI setup, all you need to do is hold down the

HIFT button and press the PANIC button in the Piano section. This will execute an internal All Notes

Off, and reset certain parameters to their default values.
