11. System functions: Sound Menu Nord Stage EX v6.x
Page 68
SOUND MENU
Press SHIFT + SOUND to access the Sound menu. Use the PAGE -/+ buttons to navigate between the
various menu items on the Sound menu. Hold a P
AGE button to scroll quickly. The VALUE DIAL is
used to change settings. When you are done, press E
XIT (SHIFT) briefly to exit the menu.
Note! The settings on the Sound menu are not saved with a Program.
The following items can be found on the Sound menu:
MIDI MENU
Press SHIFT + MIDI to access the MIDI menu. Use the PAGE -/+ buttons to navigate between the
various menu items on the MIDI menu. Hold a Page button to scroll quickly. The V
ALUE DIAL is
used to change settings, the Panel buttons to switch between A and B where applicable. When you
are done, press E
XIT (SHIFT) briefly to exit the menu.
Swell Pedal Type This setting configure the Swell Pedal. See “Ctrl
Pedal Type” above for details.
Roland (Default), Yamaha,
Ernie B, Fatar
Swell Pedal Dest This setting configure the Swell Pedal destination.
Set this to Organ if only the Organ section should be
controlled or to All if the volume of all sections should
be controlled.
Organ (Default), All
Memory Protect This is set to “On” when Nord Stage EX leaves the
factory, meaning that you cannot save any changes
to Programs or Synth Sounds. Set this to Off if you
wish to store your own Programs. System settings
and the two Live buffers are not protected by this set-
ting.
On (default), Off
Factory Reset This resets all system settings and restores the origi-
nal Live-buffers. Hold the flashing
STORE a few sec-
onds to perform the reset. The display will take a few
seconds. Stored programs are not affected by this
action (except the live buffers).
Function Description Range/Values
Synth Vibrato Rate This determines the rate of the Synth Vibrato. 4.00 - 8.00 Hz (Default
6.00 Hz)
Synth Dly Vibrato
Amount
This determines the amount of Synth Vibrato when
any of the vibrato delay modes are used.
0-50 cent (Default value is
25 cent)
Organ Key Click
Level B3
This sets the amount of Key Click for B3 organ
sounds (see
“Key click control” on page 26)
1-10 (Default value is 5)
Rotor Acc The acceleration rate of the Rotor effect, i.e. how long
it takes for the Rotor to speed up or slow down.
Slow, Mid (Default), Fast
Delay Mode This sets if the delay should change the pitch on
sounding repeats if the Rate/Tempo knob is adjusted,
or not. When set to Normal, the pitch does not
change.
Analog (Default), Normal
