Chapter 25 Access Control
GS-2024 User’s Guide
185
Table 68 AAA Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
authentication authenticationFailure 1.3.6.1.6.3.1.1.5.5 This trap is sent when
authentication fails due to incorrect
user name and/or password.
AuthenticationFailureEventO
n
1.3.6.1.4.1.890.1.5.8.15.28.2.
1
This trap is sent when
authentication fails due to incorrect
user name and/or password.
RADIUSNotReachableEvent
On
1.3.6.1.4.1.890.1.5.8.15.28.2.
1
This trap is sent when there is no
response message from the
RADIUS server.
RADIUSNotReachableEvent
Clear
1.3.6.1.4.1.890.1.5.8.15.28.2.
2
This trap is sent when the RADIUS
server can be reached.
accounting RADIUSAcctNotReachableE
ventOn
1.3.6.1.4.1.890.1.5.8.15.28.2.
1
This trap is sent when there is no
response message from the
RADIUS accounting server.
RADIUSAcctNotReachableE
ventClear
1.3.6.1.4.1.890.1.5.8.15.28.2.
2
This trap is sent when the RADIUS
accounting server can be reached.
Table 69 SNMP IP Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
ping pingProbeFailed 1.3.6.1.2.1.80.0.1 This trap is sent when a single ping probe
fails.
pingTestFailed 1.3.6.1.2.1.80.0.2 This trap is sent when a ping test
(consisting of a series of ping probes)
fails.
pingTestCompleted 1.3.6.1.2.1.80.0.3 This trap is sent when a ping test is
completed.
traceroute traceRouteTestFailed 1.3.6.1.2.1.81.0.2 This trap is sent when a traceroute test
fails.
traceRouteTestCompleted 1.3.6.1.2.1.81.0.3 This trap is sent when a traceroute test is
completed.
Table 70 SNMP Switch Traps
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
stp STPNewRoot 1.3.6.1.2.1.17.0.1 This trap is sent when the STP root
switch changes.
MSTPNewRoot 1.3.6.1.4.1.890.1.5.8.15.107.7
0.1
This trap is sent when the MSTP
root switch changes.
STPTopologyChange 1.3.6.1.2.1.17.0.2 This trap is sent when the STP
topology changes.
MSTPTopologyChange 1.3.6.1.4.1.890.1.5.8.15.107.7
0.2
This trap is sent when the MSTP
root switch changes.
