Chapter 4 The Web Configurator
GS-2024 User’s Guide
49
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a
port. These static MAC addresses do not age out.
Spanning Tree
Protocol
This link takes you to screens where you can configure the RSTP/MSTP to prevent
network loops.
Bandwidth
Control
This link takes you to screens where you can cap the maximum bandwidth allowed
from specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring This link takes you to screens where you can copy traffic from one port to another
port in order that you can examine the traffic from the first port without interference.
Link Aggregation This link takes you to screen where you can logically aggregate physical links to
form one logical, higher-bandwidth link.
Port
Authentication
This link takes you to a screen where you can configure IEEE 802.1x port
authentication as well as MAC authentication for clients communicating via the
Switch.
Port Security This link takes you to a screen where you can activate MAC address learning.
Queuing Method This link takes you to a screen where you can configure queuing with associated
queue weights for each port.
Multicast This link takes you to screen where you can configure various multicast features
and create multicast VLANs.
Auth and Acct This link takes you to screens where you can configure authentication and
accounting services via external servers. The external servers can be either
RADIUS (Remote Authentication Dial-In User Service) or TACACS+ (Terminal
Access Controller Access-Control System Plus).
Loop Guard This link takes you to a screen where you can configure protection against network
loops that occur on the edge of your network.
IP Application
Static Route This link takes you to a screen where you can configure static routes. A static route
defines how the Switch should forward traffic by configuring the TCP/IP parameters
manually.
DiffServ This link takes you to screens where you can enable DiffServ and set DSCP-to-
IEEE802.1p mappings.
DHCP This link takes you to screens where you can configure the DHCP settings.
Management
Maintenance This link takes you to screens where you can perform firmware and configuration
file maintenance as well as reboot the system.
Access Control This link takes you to screens where you can change the system login password
and configure SNMP and remote management.
Diagnostic This link takes you to screens where you can view system logs and can test port(s).
Syslog This link takes you to screens where you can setup system logs and a system log
server.
Cluster
Management
This link takes you to a screen where you can configure clustering management
and view its status.
MAC Table This link takes you to a screen where you can view the MAC address and VLAN ID
of a device attach to a port. You can also view what kind of device it is.
Table 5 Navigation Panel Links (continued)
LINK DESCRIPTION
