Chapter 33 Product Specifications
GS-2024 User’s Guide
227
The following list, which is not exhaustive, illustrates the standards supported in the Switch.
Security Static MAC forwarding, 64 entries
Block unresolved address forwarding/Port security
802.1x port based authentication with RADIUS support
SSH v1/v2
SSL
Intrusion Lock
Multiple RADIUS servers
Multiple TACACS+ servers
802.1X VLAN and bandwidth assignment.
Management Configuration by console/Telnet/web
Firmware upgrade by FTP/web/console
Configuration backup and restore by FTP/web/console
System management access control
Telnet (up to 9 sessions)
System clock by manual setup or NTP
Daylight saving time support
RMON group 1,2,3,9
ICMP echo/echo reply
System log (1000 entries)
Out-of-band Ethernet, IP host only, non-VLAN aware
SNMP v2c/v3, MIBS:
RFC1213
RFC1157
RFC1493 bridge MIB
RFC1643 Ethernet MIB
RFC1757 RMON group 1,2,3,9
RFC2674 bridge MIB extension
SNMP traps, 4 destination
syslog
Loop guard
Accounting by RADIUS
Accounting by TACACS+
Both cluster manager and client supported
Up to 24 clients supported for a group
Table 89 Switching Specifications (continued)
Table 90 Standards Supported
STANDARD DESCRIPTION
RFC 826 Address Resolution Protocol (ARP)
RFC 867 Daytime Protocol
RFC 868 Time Protocol
RFC 1112 IGMP v1
RFC 1157 SNMPv1: Simple Network Management Protocol version 1
RFC 1213 SNMP MIB II
RFC 1305 Network Time Protocol (NTP version 3)
RFC 1441 SNMPv2 Simple Network Management Protocol version 2
RFC 1493 Bridge MIBs
RFC 1643 Ethernet MIBs
