Chapter 6 System Status and Port Statistics
GS-2024 User’s Guide
61
256-511 This field shows the number of packets (including bad packets) received that were
between 256 and 511 octets in length.
512-1023 This field shows the number of packets (including bad packets) received that were
between 512 and 1023 octets in length.
1024-
1518
This field shows the number of packets (including bad packets) received that were
between 1024 and 1518 octets in length.
Giant This field shows the number of packets dropped because they were bigger than the
maximum frame size.
Table 7 Status > Port Details (continued)
LABEL DESCRIPTION
