GENERAL SPECIFICATIONS
SPEC
2 - 1
SPECIFICATIONS
GENERAL SPECIFICATIONS
Item Standard Limit
Dimensions
Overall length 2,500 mm (98.4 in) ----
Overall width 980 mm (38.6 in) ----
Overall height 1,140 mm (44.9 in): XV16A ----
1,500 mm (59.1 in): XV16AT ----
Seat height 710 mm (28.0 in) ----
Wheelbase 1,685 mm (66.3 in) ----
Minimum ground clearance 145 mm (5.71 in) ----
Minimum turning radius 3,200 mm (126 in) ----
Weight
Wet (with oil and a full fuel tank) 332 kg (732 lb): XV16A ----
347 kg (765 lb): XV16AT ----
Dry (without oil and fuel) 307 kg (678 lb): XV16A ----
322 kg (710 lb): XV16AT ----
Maximum load (total of cargo, rider,
passenger, and accessories)
196 kg (432 lb): XV16A
181 kg (399 lb): XV16AT
----
----
