Yamaha XV16ALC (1998) [41/449] Tightening torques

2 - 22

SPEC

HINWEIS:

NOTE:

1.First, tighten the ring nut to approximately 52 Nm (5.2 m • kg, 37 ft • lb) with a torque

wrench, then loosen the ring nut completely.

2.Retighten the ring nut to specification.

Rear master cylinder and rear brake

bracket

M8 23 2.3 17

Rear brake reservoir tank M6 4 0.4 2.9

Union bolt (rear brake hose) M10 30 3.0 22

Footrest bracket and rear brake bracket M8 16 1.6 11

Footrest bracket and shift rod bracket M8 16 1.6 11

Front wheel axle M18 78 7.8 56

Front wheel axle pinch bolt M8 19 1.9 13

Rear wheel axle nut M18 150 15.0 110

Front brake caliper M10 40 4.0 29

Rear brake caliper M10 40 4.0 29

Brake disc and wheel M8 23 2.3 17

Caliper bleed screw M8 6 0.6 4.3

Driven pulley and rear wheel clutch hub

M12 95 9.5 68

Rear brake caliper bracket and swin-

garm

M10 48 4.8 35

Item Thread size

Tightening torque

Remarks

Nm m·kgf ft·lb

TIGHTENING TORQUES
