PONDEROSA
99
Inputs & Outputs 33 - 64
Audio Pin Connections – I/Os 33 -64
Pin # 33-40 41-48 49-56 57-64
Pin #1 40 (+) 48 (+) 56 (+) 64 (+)
Pin #14 40 (-) 48 (-) 56 (-) 64 (-)
Pin #2 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #15 39 (+) 47 (+) 55 (+) 63 (+)
Pin #3 39 (-) 47 (-) 55 (-) 63 (-)
Pin #16 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #4 38 (+) 46 (+) 54 (+) 62 (+)
Pin#17 38 (-) 46 (-) 54 (-) 62 (-)
Pin #5 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #18 37 (+) 45 (+) 53 (+) 61 (+)
Pin #6 37 (-) 45 (-) 53 (-) 61 (-)
Pin #19 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #7 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #20 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #8 36 (+) 44 (+) 52 (+) 60 (+)
Pin #21 36 (-) 44 (-) 52 (-) 60 (-)
Pin #9 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #22 35 (+) 43 (+) 51 (+) 59 (+)
Pin #10 35 (-) 43 (-) 51 (-) 59 (-)
Pin #23 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #11 34 (+) 42 (+) 50 (+) 58 (+)
Pin #24 34 (-) 42 (-) 50 (-) 58 (-)
Pin #12 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #25 33 (+) 41 (+) 49 (+) 57 (+)
Pin #13 33 (-) 41 (-) 49 (-) 57 (-)
