PONDEROSA
49
Button Function per Panel
The functions in the following table are selected under Button Configuration. This only
applies to SCP programmable control panels.
Function
SCP-20, -112,
-132, -224, -240
SCP-150
Function
Params
Comments
None
√ √
Level
√ √
Level number
Destination
√ √
Destination
number
Source
√ √
Source number
Category
√
List of
configured
categories
Index
√
8 Character ASCII
Src/Dst name or
number
Take
√ √
Applies to all shift lvls
Select*
√
Applies to all shift lvls
Shift*
√ √
Applies to all shift lvls
Select/Shift*
√
Applies to all shift lvls
Scroll Back
√
LED Display function
Scroll Forward
√
LED Display function
Clear
√
LED Display function
Backspace
√
LED Display function
Page
√
LED Display function
Dest Lock
√ √
List of created
PINs
Global password (PIN)
= 9999
Salvo Menu
√
LED Display function
Salvo
√ √
Salvo number
Select All
Levels
√ √
Clear Dst
√
LED Display function
Clear Source
√
LED Display function
Name vs
Number
√
LED Display function
*Select toggles between fields in the display with a press and release. Shift changes button
functions to shifted modes with a press and hold.
