Kramer Sierra Ponderosa 6464HDR-64 [82/128] Input module leds

SIERRA VIDEO

Input Module LEDs

Each input module has 5 Green LEDs located on the front edge of the board. The LEDs indicate

the status of the module’s voltage. All 5 LEDs must be lit for the module to operate properly. The

absence of any lighted LED indicates a failure of the module and the factory should be contacted.

Just behind the reset button there is a group of 6 LEDs used for de-bug purposes. The function of

the LEDs are described below.

LED Indication Normal condition Color

Transmit in progress Flickers On/OFF when data is transferred GREEN

Application has run ON GREEN

Boot program has run ON GREEN

Temperature out of range OFF RED

Voltage out of range OFF RED

Not used OFF RED
