Kramer Sierra Ponderosa 6464HDR-64 [117/128] Analog audio specifications

PONDEROSA

111

Analog Audio Specifications

Gain +/- 0.5 dB

Frequency Response: 20 Hz to 20 KHz +/- 0.5 dB

Max I/O Level- Balanced +21 dB

Max I/O Level- Unbalanced +15 dB

Noise (20 Hz to 20 KHz) -79 dBu

Crosstalk: 1 KHz < -90 dB

Crosstalk: 10 KHz < -70 dB

THD+N (20 Hz to 20 KHz @ +4 dBu) < 0.025%

IM (20 Hz to 20 KHz @ +4 dBu < 0.025%

Digital Audio Specifications

AES 3 AES 3-id

I/O connections 110 ohm balanced/shielded cable 75 ohm BNC

Input/Output impedance 110 ohm +/- 20% 75 ohm

Return Loss < -15 db < -15 db

Output Voltage 2 V p-p Min 1 V p-p +/- 20%

DC Offset N/A < 50 mv

Rise/Fall Time 5 to 30 ns 30 to 44 ns

Intrinsic Jitter < 0.025 UI using intrinsic-jitter filter < 0.025 UI using intrinsic-jitter filter

Min Input Voltage 200 mv p-p 320 mv p-p

Data Rates

32 KHz to 96 KHz Sampling Rate

2.048 Mbps to 6.144 Mbps Data Rates

Meets all above specifications with 32 KHz, 44.1 KHz, 48 KHz, and 96 KHz

Sampling Rates

General

Rack Unit/ Frame Size 3RU-6464 Frame & 5RU-128128 Frame

Dimensions

6464 Frame-19” W x 5 1/4” H x 20 1/2” D

128128 Frame 8 3/4” H x 20 1/2” D

Mounts in Standard 19” rack

Depth measurements do not include rear cabling

Power

90VAC to > 240VAC Auto-detecting

<150Watts for 6464 Frame

<300Watts for 128128 Frame

Redundant Power Supply Standard

Storage Temperature -40° to +150° F

Operating Temperature 30° to 100° F Ambient

Humidity 10% to 90% Non-condensing
