SIERRA VIDEO
100
Inputs & Outputs 65 - 96
Audio Pin Connections – I/Os 65-96
Pin # 65-72 73-80 81-88 89-96
Pin #1 72 (+) 80 (+) 88 (+) 96 (+)
Pin #14 72 (-) 80 (-) 88 (-) 96 (-)
Pin #2 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #15 71 (+) 79 (+) 87 (+) 95 (+)
Pin #3 71 (-) 79 (-) 87 (-) 95 (-)
Pin #16 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #4 70 (+) 78 (+) 86 (+) 94 (+)
Pin#17 70 (-) 78 (-) 86 (-) 94 (-)
Pin #5 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #18 69 (+) 77 (+) 85 (+) 93 (+)
Pin #6 69 (-) 77 (-) 85 (-) 93 (-)
Pin #19 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #7 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #20 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #8 68 (+) 76 (+) 84 (+) 92 (+)
Pin #21 68 (-) 76 (-) 84 (-) 92 (-)
Pin #9 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #22 67 (+) 75 (+) 83 (+) 91 (+)
Pin #10 67 (-) 75 (-) 83 (-) 91 (-)
Pin #23 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #11 66 (+) 74 (+) 82 (+) 90 (+)
Pin #24 66 (-) 74 (-) 82 (-) 90 (-)
Pin #12 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #25 65 (+) 73 (+) 81 (+) 89 (+)
Pin #13 65 (-) 73 (-) 81 (-) 89 (-)
