PONDEROSA
101
Inputs & Outputs 97 - 128
Audio Pin Connections – I/Os 97-128
Pin # 97-104 105-112 113-120 121-128
Pin #1 104 (+) 112 (+) 120 (+) 128 (+)
Pin #14 104 (-) 112 (-) 120 (-) 128 (-)
Pin #2 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #15 103 (+) 111 (+) 119 (+) 127 (+)
Pin #3 103 (-) 111 (-1) 119 (-) 127 (-)
Pin #16 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #4 102 (+) 110 (+) 118 (+) 126 (+)
Pin#17 102 (-) 110 (-) 118 (-) 126 (-)
Pin #5 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #18 101 (+) 109 (+) 117 (+) 125 (+)
Pin #6 101 (-) 109 (-) 117 (-) 125 (-)
Pin #19 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #7 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #20 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #8 100 (+) 108 (+) 116 (+) 124 (+)
Pin #21 100 (-) 108 (-) 116 (-) 124 (-)
Pin #9 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #22 99 (+) 107 (+) 115 (+) 123 (+)
Pin #10 99 (-) 107 (-) 115 (-) 123 (-)
Pin #23 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #11 98 (+) 106 (+) 114 (+) 122 (+)
Pin #24 98 (-) 106 (-) 114 (-) 122 (-)
Pin #12 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #25 97 (+) 105 (+) 113 (+) 121 (+)
Pin #13 97 (-) 105 (-) 113 (-) 121 (-)
Unbalanced Audio Pin Out Example
Pin # 1-8 9-16 17-24 25-32
Pin #1 8 (+) 16 (+) 24 (+) 32 (+)
Pin #14 Ground Ground Ground Ground Ground Ground Ground Ground
Pin #2 Ground Ground Ground Ground Ground Ground Ground Ground
