Kramer Sierra Ponderosa 6464HDR-64 [81/128] Input module

PONDEROSA

Input Module

Input modules are designed in groups of eight. This allows for expansion in groups of eight

inputs. Each input module comes with a rear “backplane” panel consisting of eight BNC

connectors.

The input module is installed from the front of the frame with the BNC panel installed directly

behind the input module in the back of the frame.

Address Switches

BNC Rear Panel

Reset Button

Voltage Status

LEDs

De-bug LEDs
