SIERRA VIDEO
109
Specifications
HD Video Specifications
Video
Data Rates 19Mbps – 2.97Gbps
Data Types
SMPTE 424, 372M, 310M, 259, 344M, 292M, DVB-ASI, ITU-R
BT.601
Jitter < 0.2 UI
INPUT
Video Level 800mV p-p +/-10%
Connector Type BNC
Impedance 75 Ohm
Return Loss <-20dB up to 2.97 GHz
Cable Equalization
0 – 100 meters for SMPTE 292, 424 or 372M, Belden 1694A
0 – 300 meters for all other standards, Belden 1694A
OUTPUT
Video Level 800mV p-p +/-10%
Connector Type BNC
Impedance 75 Ohm
Return Loss <-20dB up to 2.97 GHz
Rise/Fall Times < 0.4 nsec for 270 Mbps SDI and < 135 psec for HD-SDI
Optional D to A Output Module
Return Loss <-30db @ 5 MHz
Differential Gain +/- 0.3 % @ 3.58 MHz or 4.443 MHz
Differential Phase +/- 0.5 Deg @ 3.58 MHz or 4.443 MHz
