Chapter 1: Product introduction
1-10
1.7 LED information
1.7.1 Front panel LEDs
LED Icon
Display
status
Description
Power LED ON System power ON
HDD
Access
LED
1
2
Q-Code
DM
1
2
3
4
RESET
OFF No activity
Blinking Read/write data into the HDD
Message
LED
OFF System is normal; no incoming event
ON
With the onboard ASMB8-iKVM: a hardware monitor event is
indicated
LAN LEDs
OFF No LAN connection
Blinking LAN is transmitting or receiving data
ON LAN connection is present
3
4
Blinking LAN is transmitting or receiving data
Location
LED
1
2
Q-Code
DM
1
2
3
4
RESET
ON Location switched is pressed
OFF Normal status (Press the location switch again to turn off)
1
2
Q-Code
DM
1
2
3
4
RESET
Message LED
LAN4 LED (for Mezzanine card use)
HDD Access LED
Power LED
RS400-E8-PS2
Location LED
LAN3 LED ( for Mezzanine card use)
LAN2 LED
LAN1 LED
