Asus rs400-e8-ps2 [87/178] Intel lan i210 configuration
![Asus rs400-e8-ps2 [87/178] Intel lan i210 configuration](/views2/1161716/page87/bg57.png)
ASUS RS400-E8-PS2, RS400-E8-PS2-F
5-13
Intel I210 Lan1 Enable/ Intel I210 Lan2 Enable [Enabled]
Allows you to enable or disable the Intel LAN.
Congurationoptions:[Disabled][Enabled]
Intel LAN ROM Type [PXE]
Allows you to select the Intel LAN ROM type.
Congurationoptions:[Disabled][PXE][iSCSI]
5.4.4 Intel LAN I210 Conguration
