Chapter 2: Hardware setup
2-20
2.5.3 Installing a Mezzanine card
YoucaninstallasupportedMezzaninecardontheonboardslot.
ToinstallaMezzaninecard:
1. RemovetheslotbayfromtheMezzaninecard
expansion slot.
3. Matchandinsertthefour(4)screwholesontheMezzaninecardintothefour(4)stand
screwsonthechassis,theninserttheMezzaninecardtotheslotonthemotherboard.
1
2
3
4
RESET
Q-Code
1
2
1
AUXLED_CON1
2. PrepareyourMezanninecardandthesignalcable.Connectthesignaltransmission
end(white)totheAUXLED_CONheaderonthemotherboard.
