ASUS RS400-E8-PS2, RS400-E8-PS2-F
5-5
4. Theutilityveriesthele,thenstartsupdatingtheBIOSle.
DO NOT shut down or reset the system while updating the BIOS to prevent system boot
failure!
5. The utility returns to the DOS prompt after the BIOS update process is completed.
Rebootthesystemfromtheharddiskdrive.
The BIOS update is nished! Please restart your system.
C:\>
ASUS Tek. EzFlash Utility
Start programming the Flash. DO NOT SHUTDOWN THE SYSTEM!!!
Write ...
25%
Current Platform
Platform : Z10PR-D16
Version : 0401
Build Date :09/05/2013
New Platform
Platform : Z10PR-D16
Version : 0606
Build Date :03/27/2014
