ASUS RS400-E8-PS2, RS400-E8-PS2-F
5-19
Network stack [Disabled]
Enablesordisablesthenetworkstackfeature.Congurationoptions:[Disable][Enable]
5.4.8 Network Stack Conguration
The following item appears only when Network stack is set to[Enabled].
Ipv4 PXE Support [Enabled]
EnablesordisablestheIpv4PXEBootSupport.Ifdisabled,Ipv4PXEbootoptionwill
notbecreated.Congurationoptions:[Disabled][Enabled].
Ipv6 PXE Support [Enabled]
EnablesordisablestheIpv6PXEBootSupport.Ifdisabled,Ipv6PXEbootoptionwill
notbecreated.Congurationoptions:[Disabled][Enabled].
PXE boot wait time [0]
WaittimetopressESCkeytoabortthePXEboot.
Media detect time [0]
Waittime(inseconds)todetectmedia.
