DG834G Reference Manual

Virtual Private Networking 8-15

v3.0, September 2005

• In the Network Security Policy list on the left side of the Security Policy Editor window,

click on My Identity.

• Choose None in the Select Certificate menu.

• Select IP Address in the ID Type menu. If you are using a virtual fixed IP address, enter

this address in the Internal Network IP Address box. Otherwise, leave this box empty.

• In the Internet Interface box, select the adapter you use to access the Internet. Select PPP

Adapter in the Name menu if you have a dial-up Internet account. Select your Ethernet

adapter if you have a dedicated Cable or DSL line. You may also choose Any if you will

be switching between adapters or if you have only one adapter.

• Click the Pre-Shared Key button. In the Pre-Shared Key dialog box, click the Enter Key

button. Enter the DG834G's Pre-Shared Key and click OK. In this example, 12345678 is

entered. This field is case sensitive.

Figure 8-11

Figure 8-12
