DG834G Reference Manual
6-4 Managing Your Network
v3.0, September 2005
Viewing ADSL Modem Router Status and Usage Statistics
From the Main Menu, under Maintenance, click ADSL Modem Router Status to view this screen.
The ADSL Modem Router Status menu provides status and usage information.
This screen shows the following parameters:
Figure 6-3
Table 6-1. Menu 3.2 - ADSL Modem Router Status Fields
Field Description
Account Name The Host Name assigned to the ADSL modem router in the Basic
Settings menu.
Firmware Version This field displays the ADSL modem router firmware version.
ADSL Port These parameters apply to the Internet (ADSL) port of the ADSL
modem router.
