DG834G Reference Manual
Virtual Private Networking 8-41
v3.0, September 2005
This setting applies to both IKE and IPSec SAs. When configuring the remote endpoint to match
this setting, you may have to specify the "Key Group" used. For this device, the "Key Group" is
the same as the "DH Group" setting in the IKE section.
Example of Using Auto Policy
Figure 8-41: Gateway-to-Gateway VPN Tunnel
1. Set the LAN IPs on each DG834G to different subnets and configure each properly for the
Internet. The following settings are assumed for this example:
A
B
VPN Tunnel
DG834G VPN
Firewall
DG834G VPN Firewall
PCs
PCs
192.168.0.1
192.168.3.1
14.15.16.17
22.23.24.25
