DG834G Reference Manual
C-16 NETGEAR VPN Configuration
v3.0, September 2005
Step 1: Configuring the Client-to-Gateway VPN Tunnel on the
VPN Router at the Employer’s Main Office
Follow this procedure to configure a client-to-gateway VPN tunnel by filling out the VPN Auto
Policy screen.
1. Log in to the VPN router at its LAN address of http://192.168.0.1 with its default user name of
admin and password of password. Click the VPN Policies link in the main menu to display
the VPN Policies screen. Click Add Auto Policy to proceed and enter the information.
