DG834G Reference Manual
6-14 Managing Your Network
v3.0, September 2005
– Day for sending log
Specifies which day of the week to send the log. Relevant when the log is sent weekly or
daily.
– Time for sending log
Specifies the time of day to send the log. Relevant when the log is sent daily or weekly.
If the Weekly, Daily or Hourly option is selected and the log fills up before the specified
period, the log is automatically e-mailed to the specified e-mail address. After the log is sent, it
is cleared from the ADSL modem router’s memory. If the ADSL modem router cannot e-mail
the log file, the log buffer may fill up. In this case, the ADSL modem router overwrites the log
and discards its contents.
Running Diagnostic Utilities and Rebooting the ADSL
Modem Router
The Wireless ADSL Modem Router has a diagnostics feature. You can use the diagnostics menu to
perform the following functions from the ADSL modem router:
• Ping an IP Address to test connectivity to see if you can reach a remote host.
• Perform a DNS Lookup to test if an Internet name resolves to an IP address to verify that the
DNS server configuration is working.
• Display the Routing Table to identify what other ADSL modem routers the ADSL modem
router is communicating with.
• Reboot the ADSL modem router to enable new network configurations to take effect or to
clear problems with the ADSL modem router’s network connection.
