DG834G Reference Manual
8-44 Virtual Private Networking
v3.0, September 2005
— Remote Identity Type = use default setting
• Parameters
— Encryption Algorithm = 3DES
— Authentication Algorithm = MD5
— Pre-shared Key = 12345678
