DG834G Reference Manual
NETGEAR VPN Configuration C-3
v3.0, September 2005
The LAN Addresses used in this example are as follows.
• DG834G
WAN IP = 14.15.16.17
LAN IP = 10.5.6.1
LAN Subnet Mask = 255.255.255.0
•FVL328
WAN IP = 22.23.24.25
LAN IP = 172.23.9.1
LAN Subnet Mask = 255.255.255.0
a. In Step 1, enter toFVL328 for the Connection Name.
b. In Step 2, enter 22.23.24.25 for the remote WAN's IP address.
c. In Step 3, enter the following:
• IP Address = 172.23.9.1
• Subnet Mask = 255.255.255.0
