DG834G Reference Manual
NETGEAR VPN Configuration C-5
v3.0, September 2005
2.
Configure the FVL328 as in the Gateway-to-Gateway procedures for the VPN Wizard (see
“How to Set Up a Gateway-to-Gateway VPN Configuration“ on page -20), being certain to
use appropriate network addresses for the environment.
a. In Step 1, enter toDG834 for the Connection Name
b. In Step 2, enter 14.15.16.17 for the remote WAN's IP address
c. In Step 3, enter the following:
• IP Address = 10.5.6.1
• Subnet Mask = 255.255.255.0
