DG834G Reference Manual
NETGEAR VPN Configuration C-27
v3.0, September 2005
1.
To launch this function, click on the Windows Start button, then select Programs, then 54
Mbps Wireless ADSL Modem Router Model DG834G, then Log Viewer.
2. The Connection Monitor screen is shown below:
Figure C-25: Connection Monitor screen
While the connection is being established, the Connection Name field in this menu will show SA
before the name of the connection. When the connection is successful, the SA will change to the
yellow key symbol.
Note: Use the active VPN tunnel information and pings to determine whether a failed
connection is due to the VPN tunnel or some reason outside the VPN tunnel.
