126

Figure 11.29

The option keys at the bottom of the screen work as below.

【1】Visual inspection of engine oil

【2】Visual inspection of particulate filter

【3】Function check of swirl flaps

【4】Exhaust backpressure test

【5】Actual/target value check-mass air flow sensor

【Back】Return to the previous menu

【1】Visual inspection of engine oil

a) From the particle filter test menu (Figure 11.29) use the

LEFT/RIGHT scroll button to select 【1】and press the OK

button.

Figure 11.30
