Autel MaxiCheck DPF Reset [57/145] A manual reset

There are two ways to perform the reset service.

A. Manual Reset

Almost all Asian vehicles and most American and European

vehicles can be reset manually by technicians.

NOTE: In this manner, the scan tool will not communicate

with the vehicle being tested.

To finish this procedure, please follow these steps (Taking Ford as

an example):

1) From the vehicle make screen, select Ford and press OK

button.

Figure 7.1

2) Step by step, select the right options for your vehicle according

to each screen that appears.

Figure 7.2

Model

1.Explorer

2.Freestyle

3.Windstar
