Autel MaxiCheck DPF Reset [62/145] Backspace uses this key to erase the previous digit or character when typing

 For the First maintenance threshold, you have two choices.

Select the correct option and press OK button to save the

change.

Figure 7.14

 For the Period before service or Maintenance limit, press

Edit key on the bottom to pop up a soft keyboard to

facilitate your input.

Figure 7.15

The three keyboard function keys work as below.

Finish --- When you finished the input, select this key to

confirm your input and exit.

Pre. --- Moves a space to the left.

Backspace --- Uses this key to erase the previous digit or

character when typing.
