- 20 -
After you login into the Web Configuration of the camera, the main page
will appear as below:
The main page of the Web Configuration provides you with many useful
information and functions, including:
Camera Information
– Displays the camera’s location and the
current date & time. The information can be modified in the Web
Configuration.
Live View Image
– Displays the real-time image of the connected
camera.
Pan/Tilt Buttons
Compression Buttons
Live View/Setup Switch
Camera Information
Live View Image
Zoom In Buttons
Nightmode Button
Function Buttons
