156

The following entries are displayed on this screen:



Packets Received

BOOTREQUEST: Displays the Bootp Request packet received.

DHCPDISCOVER: Displays the Discover packet received.

DHCPREQUEST: Displays the Request packet received.

DHCPDECLINE: Displays the Decline packet received.

DHCPRELEASE: Displays the Release packet received.

DHCPINFORM: Displays the Inform packet received.



Packets Sent

BOOTREPLY: Displays the Bootp Reply packet sent.

DHCPOFFER: Displays the Offer packet sent.

DHCPACK: Displays the Ack packet sent.

DHCPNAK: Displays the Nak packet sent.

Configuration Procedure (using VLAN interface as an example):

Step Operation Description

Set the link type for port. Required. On the VLAN→802.1Q VLAN→Port Config page,

set the link type for the port basing on its connected device.

Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config

page, click the Create

button to create a VLAN. Enter the

VLAN ID and the description for the VLAN. Meanwhile,

specify its member ports.

Create VLAN interface. Required. On the Routing→Static Routing→Static Routing

Config page, create the interface IP address of the VLAN.

Enable DHCP Server. Required. On the Routing→DHCP Server→DHCP Server

page, enable the DHCP Server function.

Configure Excluded IP

Address.

Optional. On the Routing→DHCP Server→DHCP Server

page, configure the Excluded IP Address which cannot be

assigned by the switch.

Configure IP Pool. Required. On the Routing→DHCP Server→Pool Setting

page,

configure the parameters of IP Pool, including Mask,

lease time, gateway and DNS address.

Bind IP Manually Optional. On the Routing→DHCP Server→Manual Binding

page, you can specify the IP address for specific clients.
